Imaging: device 1/3 CMOS Aptina AR0130 Valid pixel :1280*720(25fps/30fps/50fps/60fps) default 25fps TV system:PAL/NTSC Horizontal Resolution:1280H Signal-to-noise ratio:≥80dB Minimum illuminance:0.01LUX Backlight compensation(BLC) :AUTO AES :AUTO/ 1/50(1/60)-1/100,000sec AWB:AUTO Day&Night External control (IR-CUT) IR control input voltage:DC 3V-8V Video output:HD-SDI(720P) Video and video occupying space:1min≈45MB Working voltage:DC12V/75mA ±5mA Work environment:-20℃ --- 50℃
l Use high performance Sony CCD
l High resolution, 700TVL, clear and delicate image
l Low illumination, color 0.001Lux@ (F1.2, AGC ON), 0.0001Lux@ (F1.2, AGC ON, sensitivity 512), black and white 0.0001Lux @
(F1.2,AGC on),0.00001Lux LUX @(F1.2,AGC on,SouthEdvor××512)
l Support ICR infrared filter automatic switching, automatic color turn black function, to achieve day and night monitoring.
l Support wide dynamic range greater than 75dB, suitable for backlighting environment monitoring
l Support OSD menu control, suitable for customer-defined settings
l Support 3D digital noise reduction function
l Support SMART IR Technology
l Support digital anti shake function
l Support digital magnification
l Support intelligent mist removal function
l Support coaxial visual control (Pelco-C protocol) function, compatible with standard Pelco-C coaxial control device.
l Support automatic diaphragm function (DC drive)
l Convenient back focus adjustment
Application scene
It is suitable for places such as finance, supermarket, telecommunication, government, school, airport, factory, hotel, museum and so on. It is especially suitable for places such as the intersection of bright and dark, the bank counter and so on.
Imaging: device 1/3 CMOS Aptina AR0130
Valid pixel :1280*720(25fps/30fps/50fps/60fps) default 25fps
TV system:PAL/NTSC
Horizontal Resolution:1280H
Signal-to-noise ratio:≥80dB
Minimum illuminance:0.01LUX
Backlight compensation(BLC) :AUTO
AES :AUTO/ 1/50(1/60)-1/100,000sec
AWB:AUTO
Day&Night External control (IR-CUT)
IR control input voltage:DC 3V-8V
Video output:HD-SDI(720P)
Video and video occupying space:1min≈45MB
Working voltage:DC12V/75mA ±5mA
Work environment:-20℃ --- 50℃
